Introducing the Night Owl Thermal Driving Camera – 2024 Upgraded Model with User-Replaceable Lens and Higher Resolution:
The Night Owl™ HD thermal camera boasts high-definition thermal vision, featuring a 400x300 thermal sensor and 768x576p output resolution. Its versatility is highlighted by standard video connectors that can be effortlessly linked to any screen or video input. This thermal camera finds applications in a wide range of vehicles, including cars, RVs, armored vehicles, off-road trucks, and overland campers.
Speedir thermal driving camera empowers you to see beyond the limitations of visible light, revealing pedestrians, animals, and vehicles even in challenging conditions like fog, smoke, and dust. The standout feature of this camera is its remarkable long detection distance, capable of discerning heat sources up to 3000 feet beyond the reach of standard vehicle headlights.
Speedir thermal night vision offers a unique infrared imaging solution for driving that leverages thermal energy and heat signatures to generate a camera-like display. These heat sensors do not rely on visible light, enabling you to observe objects through obstructions such as dust, darkness, and dense vegetation. When integrated into vehicles, Speedir's systems greatly enhance your driving safety by effortlessly detecting hard-to-see hazards on the road. Whether it's the dead of night or amidst a swirling dust storm, you can now observe animals, pedestrians, and other vehicles with ease using Speedir's cutting-edge technology.
Thermal Vehicle Camera
Speedir’s unique infrared imaging cameras use thermal energy and heat signatures to create a viewable, camera-like display. As heat sensors, these systems require no visible light, allowing you to view subject matter through dust, darkness, and even vegetation. When equipped to vehicles, Speedir’s appliances aid your driving safety by effortlessly perceiving hard-to-see roadway threats. View animals, pedestrians, and other vehicles with ease, in the dead of night or the thick of a dust storm!
Thermal Imager Specs:
- Dimension: 2.3" X 1.5" X 1.4"
- Rated Voltage: DC 9V-32V
- Power Consumption: 9w
- Output resolution: HD 768x576p @25hz
- Visual Angle: 37° x 28°
- Sensor Resolution: 400x300
- Frame Frequency: 25hz
- Pixel Pitch: 17 µm
- Operating Temperature: -40°F to 158°F
- Waterproof Rate: IP68
- Heat Detection: 3000ft +
- Video Format: CVBS
- Supply Voltage: 9v-32v
- Startup time: 8s
- Heater: Starts automatically below 35.5 °F ( 2°C)
- Operating Temperature: -40~185 °F (-40~85 °C)
Summary of estimated costs of a wildlife vehicle collusion for a deer, elk, and moose (source: www.fhwa.dot.gov.)
Description | Deer | Elk | Moose |
Vehicle repair cost per collision | $1,840 | $3,000 | $4,000 |
Human injuries per collision | $2,702 | $5,403 | $10,807 |
Human fatalities per collision | $1,671 | $6,683 | $13,366 |
Towing, accident attendance and investigation | $125 | $375 | $500 |
Monetary value animal per collision | $2,000 | $3,000 | $2,000 |
Carcass removal and disposal per collision | $50 | $100 | $100 |
Total | $8,388 | $18,561 | $30,773 |
What Is Thermal Imaging?
Night driving aid (Full driving visibility in harsh weather, low-light, or otherwise obscured environments) View More
World-Class Service
Optimized cost for top tier tech. Customizable client-focused options for mass manufacturers. Long-term distributor. View More
Advanced Technology
Independent study and manufacture of product’s core components. 18+ years of research and development.View More
Pre-sales consulting
Provide users with a live demonstration of product and technical advice
Sales support
Professionals guide the whole project to ensure the quality
After-sales training
To provide calibration and upgrade service
Warranty
Limited 2 years warranty
